Will it get through the door?

A doorway is easy and everybody checks it. The corner is what catches people, because the constraint is not either corridor’s width — it is the pair. Two 5 ft corridors meeting at a right angle will not pass a 12 ft item, however large the room at either end.

Three tape measurements, before anybody is standing in a corridor with a piano. A venue’s own dock drawings beat this. Guest access is a different route and is not written here.

The thing, and the route

A 16 ft bar top does not reach the room. It stops at the tightest right-angle turn, and it stops there whatever the room measures.

The route

  1. The narrowest doorway

    Clear

    A 16 ft bar top passes a 3 ft × 7 ft opening in its upright orientation. Check the approach and turning space separately.

  2. The tightest right-angle turn

    Stops here

    A 16 ft bar top uses 16 ft of length, and a 5 ft into 5 ft turn takes up to 9.1 ft at 2.5 ft wide. The worst moment of the turn decides it.

The corner is the one people do not check. Two 5 ft corridors meeting at a right angle will not pass a 12 ft item, however large the room at either end — the worst moment of the turn decides it, not the corridor widths on their own. A venue’s own dock drawings beat this.

Save this as a freight route

Only a stage marked measured is stored as a measurement. Unknown stays unknown. Not applicable is stored as that. Lift height is not filled in from a typical car, and the car size is not turned into a load rating.
